Description
| No. | PARTS | MATERIAL | ||
| 1 | BODY | WCB | CF8 | CF8M |
| 2 | DISC | CF8 | CF8 | CF8M |
| 3 | SPRING | 304 | 304 | 316 |
| 4 | GASKET | PTFE | ||
| 5 | BONNET | WCB | CF8 | CF8M |
Outline and connecting measurememt
| SIZE | D | L | D | |
| 1/4″ | DN6 | 10 | 52 | 32 |
| 3/8″ | DN10 | 12 | 52 | 32 |
| 1/2″ | DN15 | 14 | 60 | 35 |
| 3/4″ | DN20 | 19 | 69 | 40 |
| 1″ | DN25 | 24 | 80 | 46.5 |
| 1-1/4″ | DN32 | 31 | Q7 01 |
56 |
| 1-1/2″ | DN40 | 38 | 100 | 67 |
| 2″ | DN50 | 49 | 119 | 80.5 |
